Processing

Our in-house processing capabilities are purposefully aligned to meet our customer's requirements within the exacting Naval and Shipbuilding sectors; from Shotblasting & Painting, Profiling, Bevelling, Etching and Bar Cutting, we provide comprehensive supply chain solutions and operational excellence.

Shotblasting & Painting

Our Geitart fully-automated shotblast & paint line is the largest operation of its kind in the United Kingdom.

Built & further developed specifically to serve the Naval and Shipbuilding industries with high-quality at scale processed steels.

Our ability to shotblast and paint steels up to 18,000mm long and 4,000mm wide means we are the perfect supply partner for newbuild vessel programs, vessel repair and large infrastructure projects.

  • Capacity

    50,000 mt/annum

  • Max. Length

    18,000mm

  • Max. Width

    4,000mm

  • Max. Height

    600mm

Efficient Shotblasting & Coating Solutions

  • Metallic shot to top & underside simultaneously

  • Automatic blasts media removal & recycle

  • Utilising pre and post air-dryer for optimal results

  • Industry standard paint specifications

  • Pre, mid, and post inspections

  • Reliable and durable, high-quality end products

  • Qualified NACE Inspector

  • ICATS accredited

  • Low emissions

Highly efficient blasting quality of BSA 2.5 according to ISO8501-1: 2007

Before imageAfter image

Profiling

Housing three independent automated profile-cutting machines at our site in Bradford, West Yorkshire, we are the trusted delivery partner for some of Europe’s largest engineering and fabrication companies across the Marine & Naval, Material Handling, Construction & other sectors.

ESAB® Plasma

  • Thickness Range

    4mm - 30mm

  • Max. Length

    28,000mm

  • Max. Width

    3,400mm

ESAB® Gas

  • Thickness Range

    6mm - 120mm

  • Max. Length

    12,000mm

  • Max. Width

    3,000mm

Techserv® 5-head

  • Thickness Range

    6mm - 110mm

  • Max. Length

    16,000mm

  • Max. Width

    3,400mm

Third Party Inspection & Testing

We offer a range of third-party tests in accordance with your specific project requirements.

The following tests can be carried out upon request.

  • Witness testing to class (Lloyds Register, DNV, ABS, BV, other)

  • Chemical, Mechanical &/or Tensile proving tests

  • Through Thickness Test to EN10164:2018 Z15, Z25, Z35

  • Ultrasonic Test to EN10160
